GM-L · MULTISOURCE LED
GML WASH 3740
Zoom 10–60°37 × 25W RGBW 4-in-1 High CRI
GML WASH 3740
Product Overview
Concept and Optical Capabilities
The GML WASH 3740 High CRI is a professional LED wash moving head engineered for broadcast studios, theatre stages, and concert venues requiring superior color fidelity (CRI>95). Its optical array houses 37 × 25W RGBW 4-in-1 LEDs designed for authentic skin tone rendition and rich saturation.
Key Functional Features
- Zonal Ring Control: Concentric LED ring segmentation allows independent zone modulation and animated surface graphic patterns.
- Optical System and Motorized Zoom: A 10–60° zoom mechanism produces smooth transitions from a narrow key beam to extensive stage wash coverage.
- Color Precision and CCT: Linear RGBW color mixing with an adjustable white spectrum from 2700K to 8000K, coupled with built-in color macro presets.
- Control and Interfacing: DMX512 and RDM compatibility across 10/15/21/37/39 channel modes, invertible LCD display, PowerCON in/out, and 3-pin and 5-pin XLR connections.
Application Scope
High CRI (>95) output coupled with low thermal emission makes this luminaire tailored for on-camera broadcast, architectural key lighting, and premier auditorium productions.
Product variants
2 variants available
Active:Standard
Standard:Flagship wash moving head with 37x40W Osram RGBW LEDs and individual ring pixel control.
03 // TECHNICAL SPECIFICATIONS
Specifications
Zoom range
10–60°
Strobe
1–25 Hz, random and pulse flash
Tilt movement
270°
Light source
37 × 25W RGBW 4-in-1 High CRI LED
Color rendering index (CRI)
>95
Light source lifetime
50,000 h
Color temperature
2700–8000 K
Color mixing
RGBW linear color mixing adjustment
Color macro mode
Outstanding color macro mode
Zone control
Concentric ring control (Rings control)
Control protocols
DMX512, RDM
DMX channels
10/15/21/37/39 channels
Control connectors
3-pin & 5-pin XLR IN / OUT
Input voltage
AC 90–240V, 50/60 Hz
Power consumption
980 W (@ 220 V)
Power connectors
PowerCON IN / OUT
Fixture dimensions
410 × 200 × 465 mm
Net weight
17 kg
Fixture type
LED Moving Head Wash Luminaire
Dimmer
Electronic 0–100%
Pan movement
540°
Display
LCD display with display flip
IP rating
IP20
