GML 360 BATTERY TUBE Wireless 360° Battery Pixel LED Tube

Concept and Optical Performance

The GML 360 BATTERY TUBE is an IP65 all-weather wireless battery pixel LED tube equipped with a 9600 mAh rechargeable lithium battery pack, designed for cable-free operation on live stages, outdoor sets, and architectural activations. The 360° omnidirectional optical engine features 192 × 0.2W RGBWA 5-in-1 LEDs mapped across 32 individually addressable pixel zones. Integrated CCT tuning spans 1750K to 10000K in 250K increments with high color fidelity.

Battery Autonomy and Enclosure

Encased in a sand-oxidized aluminum alloy chassis, the tube maintains structural durability and natural heat dissipation without noisy fans. Operating runtime lasts up to 8 hours in single-color wash and up to 12 hours under user-selected power saver presets, with a full recharge completed in 7 hours. Supplied accessories include rigging eyebolts, a foldable floor stand, an infrared remote, and a charging unit. Dimensions are 1435 mm length by 50 mm diameter with a lightweight build of 2.5 kg.

Wireless Control Integration

Control protocols encompass Wireless DMX (CRMX compatible), 2.4G mobile app connectivity, IR remote, Madrix playback, and Master-Slave synchronization across 4, 5, 6, 7, 12, 40, 80, and 160-channel profiles. Onboard programming is accessed via a responsive OLED touch display.
