GML 1815 BAR IP All-Weather LED Wall Washer Bar

GML 1815 BAR IP All-Weather LED Wall Washer Bar

The GML 1815 BAR IP is designed for uniform wall washing, architectural perimeter illumination, and outdoor stage backdrops (IP65). Its optical array features 18 × 15W RGBW 4-in-1 LEDs with a 50,000-hour service lifespan, supporting high-speed pixel running patterns and pre-programmed chase macros.

Pixel Mapping and Dynamic Macros

Dynamic capabilities include independent pixel mapping across all 18 LED cells alongside internal program macros. DMX profiles cover 5, 9, 90, and 94 channels, with the 90CH and 94CH modes granting individual RGBW parameter control for each emitter.

Chassis and Interface

Built with die-cast aluminum for natural convection cooling and outdoor resilience (IP65), the fixture weighs 2.5 kg. Standalone and networked functionality covers USITT DMX512, auto-run sequences, master/slave synchronization, and sound activation. Physical connections provide Powercon in/out and 3-pin XLR in/out sockets. Dimensions are 980 × 81 × 150 mm.
